Thread: High-quality black-and-white photographs of large old machines and tools

  1. #751
    Supporting Member Isambard's Avatar
    Join Date
    Aug 2019
    Location
    Hawke's Bay, New Zealand
    Posts
    156
    Thanks
    0
    Thanked 55 Times in 35 Posts
    "For those who don't know doing a 3 start *TPI thread you only make the cuts as deep as if you were doing a 24TPI but you must be precisely 120° between starts"

    Memory fade Frank?
    Thread depth is as normal. However the lathe must be capable of thread cutting at 1/3 of the tpi. i.e 3 start 12 TPI would cut at 4 TPI.

    186 More Best Homemade Tools eBook

  2. The Following User Says Thank You to Isambard For This Useful Post:

    jimfols (Jun 3, 2022)

  3. #752
    Supporting Member Toolmaker51's Avatar
    Join Date
    Feb 2016
    Location
    Midwest USA
    Posts
    5,334
    Thanks
    7,044
    Thanked 3,011 Times in 1,900 Posts

    Toolmaker51's Tools
    Quote Originally Posted by Frank S View Post
    Making large diameter threads is not much of a task. I've made both internal and external 18" diameter threads 4 TPI on a 16" gap bed lathe using a homemade 20 inch diameter face plate instead of a chuck to take advantage of more of the gap Obviously not hex stock. One of the strangest threads for me at least was when I made a 3 start 8 TPI thread full length on a 4inch diameter bar and the nuts to go with it.
    For those who don't know doing a 3 start *TPI thread you only make the cuts as deep as if you were doing a 24TPI but you must be precisely 120° between starts
    All the more reason to have a degree wheel, or degree tape prepared in advance; it'd be utterly correct to have a vernier or some means to locate quadrants accurately. Something tells me a Pi tape (easily determines .001 -.0005 accurately) and a fine tipped pointer is just the ticket. Not much reason beyond 2-3 and 4's.

    2,000+ Tool Plans
    Sincerely,
    Toolmaker51
    ...we'll learn more by wandering than searching...

  4. The Following User Says Thank You to Toolmaker51 For This Useful Post:

    Frank S (Jun 3, 2022)

  5. #753
    Supporting Member
    Join Date
    Oct 2016
    Posts
    1,113
    Thanks
    25
    Thanked 347 Times in 244 Posts

    old kodger's Tools
    I recently had to go the other way and produce a 2tpi mandrel 50mm in diameter to make a coil in 10mm stainless tube

  6. #754
    Supporting Member Toolmaker51's Avatar
    Join Date
    Feb 2016
    Location
    Midwest USA
    Posts
    5,334
    Thanks
    7,044
    Thanked 3,011 Times in 1,900 Posts

    Toolmaker51's Tools
    10mm stainless? Coil? 50mm x 2 TPI?
    It's OK, you can tell us.
    Ain't heard tell'a revnu-oors here bouts.

    OMG! Have I committed a serious bit of stereotyping?
    Sincerely,
    Toolmaker51
    ...we'll learn more by wandering than searching...

  7. #755
    Jon
    Jon is online now Jon has agreed the Seller's Terms of Service
    Administrator
    Supporting Member
    Jon's Avatar
    Join Date
    Jan 2012
    Location
    Colorado, USA
    Posts
    26,433
    Thanks
    8,100
    Thanked 40,246 Times in 11,775 Posts
    Furnace from the Mesta Forge Department. West Homestead, Pennsylvania. Circa 1915-1925.

    Fullsize image: https://diqn32j8nouaz.cloudfront.net...t_fullsize.jpg


  8. The Following User Says Thank You to Jon For This Useful Post:

    nova_robotics (Jun 6, 2022)

  9. #756
    Supporting Member bruce.desertrat's Avatar
    Join Date
    Nov 2017
    Posts
    809
    Thanks
    591
    Thanked 687 Times in 369 Posts

    bruce.desertrat's Tools
    Wow, didn't know Mesta had a line of miniature machines :-) That looks hardly taller than a worker!

  10. #757
    Supporting Member Toolmaker51's Avatar
    Join Date
    Feb 2016
    Location
    Midwest USA
    Posts
    5,334
    Thanks
    7,044
    Thanked 3,011 Times in 1,900 Posts

    Toolmaker51's Tools
    Awful good estimation by bruce.desertrat.
    Perhaps MESTA acquired it via auction lot; didn't know something so small was included?

    Common brick is 2.25" high. Foundation is 5 courses with 4 mortar joints @~.6 (judging by the stack of 6 at left front corner) or kind of 13-5/8". Furnace box about 4x that 13.6, or 61"; 61"+13.6= ~74.8" (74.8/12 = 6.2').

    Noooo, didn't stay at Holiday Inn last night, did employ Gerber Vari-Scale though. Enjoyable device, once in awhile wish it wasn't two feet long.
    (drumroll please, cue for marksbug...)
    Sincerely,
    Toolmaker51
    ...we'll learn more by wandering than searching...

  11. #758
    Jon
    Jon is online now Jon has agreed the Seller's Terms of Service
    Administrator
    Supporting Member
    Jon's Avatar
    Join Date
    Jan 2012
    Location
    Colorado, USA
    Posts
    26,433
    Thanks
    8,100
    Thanked 40,246 Times in 11,775 Posts
    Wire mesh machine. American Steel and Wire Co. Donora, PA. Circa 1915.

    Fullsize image: https://diqn32j8nouaz.cloudfront.net...t_fullsize.jpg


  12. The Following 3 Users Say Thank You to Jon For This Useful Post:

    jimfols (Jun 12, 2022), nova_robotics (Jun 13, 2022), Toolmaker51 (Jun 12, 2022)

  13. #759
    Supporting Member Toolmaker51's Avatar
    Join Date
    Feb 2016
    Location
    Midwest USA
    Posts
    5,334
    Thanks
    7,044
    Thanked 3,011 Times in 1,900 Posts

    Toolmaker51's Tools
    Too bad this photographer wasn't in charge of the Brazilian line shaft shop...Line shaft driven factory and workers. Brazil, 1880, post 2613.
    Sincerely,
    Toolmaker51
    ...we'll learn more by wandering than searching...

  14. #760
    Supporting Member IntheGroove's Avatar
    Join Date
    May 2019
    Location
    Lake Tahoe
    Posts
    2,093
    Thanks
    195
    Thanked 944 Times in 573 Posts

    IntheGroove's Tools
    Post #585 shows the other side of that machine...
