    five setups with an edge finder

    five setups with an edge finder
    but there are 6 that i know of or could remember
    on the 5the segment i included 2
    this video was made to instruct my students on the how to on "setups"
    the general use and maintenance video will come later
    with this video i tried a new editing style (video interacting with photos to try and get a better understanding)

    five setups with an edge finder-edge-finder.png

    186 More Best Homemade Tools eBook

  2. The Following User Says Thank You to shopandmath For This Useful Post:

    EnginePaul (Jun 30, 2019)

  3. #2
    Supporting Member
    Join Date
    Nov 2017
    Posts
    401
    Thanks
    38
    Thanked 209 Times in 116 Posts

    Elizabeth Greene's Tools
    I wish I'd had this when I was learning how to use one. I have one of those double-ended edge finders and unfortunately I'm self taught. It took more than a little scratching to figure out I was supposed to hold it by the center body and not the end.

    Whoops.

    2,000+ Tool Plans

  4. The Following User Says Thank You to Elizabeth Greene For This Useful Post:

    shopandmath (Jun 27, 2019)

  5. #3
    Supporting Member shopandmath's Avatar
    Join Date
    Jun 2019
    Location
    Kitchener ON,CA,
    Posts
    238
    Thanks
    200
    Thanked 359 Times in 105 Posts

    shopandmath's Tools
    Hi Elizabeth
    thank you for your reply
    I am trying to develop a style that a student can visualize and repeat when delivered in small chunks
    Ray :-)

  6. #4
    Supporting Member Toolmaker51's Avatar
    Join Date
    Feb 2016
    Location
    Midwest USA
    Posts
    5,334
    Thanks
    7,044
    Thanked 3,011 Times in 1,900 Posts

    Toolmaker51's Tools
    We can also locate [via pointed edge finder] accurately scribed centers by setting the point in one axis of scribed line LIGHTLY, then move axis until the body and point measure concentric [by feel or micrometer] then the other and recording each position. Some use a fingernail to detect the offset; I use .003 feeler gauge. Small clean holes can be done the same way.
    It's good to have a selection of edge finders. The .200 Ø are popular, but aren't ideal centering on larger shafts. .500 Ø, not having that neck work, until the amount chucked and remaining section won't reach the centerline of bar.
    But all-told, I use a static dowel, or round body above flutes of an endmill nearly as often.
    Sincerely,
    Toolmaker51
    ...we'll learn more by wandering than searching...

  7. The Following User Says Thank You to Toolmaker51 For This Useful Post:

    shopandmath (Aug 3, 2019)

  8. #5
    Supporting Member shopandmath's Avatar
    Join Date
    Jun 2019
    Location
    Kitchener ON,CA,
    Posts
    238
    Thanks
    200
    Thanked 359 Times in 105 Posts

    shopandmath's Tools
    toolmaker 51
    thank you for your reply
    this video was made for my students to give them an idea of what they can do with an edge finder
    there is a sixth use that i missed it was locating a round part vertically in a vice
    toolmaker 51 thank you for your input I might use it in a more advanced video
    Ray :-)

  9. The Following User Says Thank You to shopandmath For This Useful Post:

    Toolmaker51 (Aug 3, 2019)

  10. #6
    Supporting Member Toolmaker51's Avatar
    Join Date
    Feb 2016
    Location
    Midwest USA
    Posts
    5,334
    Thanks
    7,044
    Thanked 3,011 Times in 1,900 Posts

    Toolmaker51's Tools
    Happy knowing somewhere, genuine vocational courses are still offered. I'd throttle whoever first decided it was no longer viable elective curriculum.



    2,000+ Tool Plans
    Sincerely,
    Toolmaker51
    ...we'll learn more by wandering than searching...
